FRP pultruded grating is a high-strength, lightweight structural flooring material made by pulling continuous glass fiber rovings and mats through a resin bath and then a heated steel die. The pultrusion process aligns the fibers in one direction, which gives the grating exceptional stiffness and load-bearing capacity along the length of its bearing bars. AMMS Global supplies this type of grating for industrial walkways, offshore platforms, trench covers, and chemical processing areas where corrosion resistance and long spans matter more than initial material cost.
What Defines Pultruded Grating
Unlike molded grating, where resin and glass are formed under pressure in a mold, pultruded grating is built from parallel load-bearing bars, typically I-bars or T-bars, joined by cross-rods. The glass content runs roughly 60% to 70% by weight, significantly higher than molded grating. That high glass-to-resin ratio is what gives pultruded panels their superior stiffness and span capability.
The trade-off is directionality. Pultruded grating is strongest along the axis of the bearing bars. Loads applied perpendicular to that axis rely on the cross-rods and the panel’s overall geometry, so span direction matters during design. Molded grating, by contrast, offers more uniform strength in both directions, which is why the choice between the two often comes down to load orientation and required clear spans.
Common Resin Systems and Their Limits
Three resin systems dominate the category. Isophthalic polyester, often called ISOFR, handles moderate corrosion and is the standard choice for general industrial use. Vinyl ester resin, or VEFR, resists stronger acids, alkalis, and solvents, making it the preferred option for chemical plants, pickling lines, and coastal installations. Phenolic resin adds high-temperature performance and low smoke and toxicity characteristics, which matter in offshore platforms, tunnels, and enclosed spaces where fire safety is regulated.
Selecting the wrong resin is a common mistake. A panel that performs well in a water treatment plant may degrade quickly in a chlorine-rich environment. The resin system, not the glass, determines chemical compatibility, so it should be specified against the actual exposure list rather than a generic “FRP” requirement.
Pultruded vs. Molded Grating
Factor | Pultruded Grating | FRP Molded Grating |
Strength direction | Unidirectional, along bearing bars | Bi-directional, more uniform |
Glass content | Around 60% to 70% by weight | Lower, typically 30% to 40% |
Span capability | Longer spans with less deflection | Shorter spans, thicker panels needed |
Impact resistance | Good, but more rigid | More flexible, absorbs impacts better |
Typical bearing bars | I-bars, T-bars, wide T-bars | Square or rectangular mesh grid |
Best suited for | Walkways, platforms, long-span covers | Chemical pits, irregular shapes, heavy impact |
Pultruded grating generally wins when spans exceed what molded panels can handle without intermediate supports. FRP Molded Grating often wins where chemical splash, foot traffic from all directions, or frequent impact loads are the primary concern.
Applications Where Pultruded Grating Excels
The product shows up most often in industrial walkways and platforms where support beams are spaced far apart. Its stiffness allows wider support spacing, which reduces the amount of structural steel required underneath. Offshore and marine structures use it for decks, stair landings, and cable tray covers because it does not corrode in salt spray and weighs far less than steel.
Heavy-duty trench covers and vehicular access panels are another strong application. Manufacturers such as Fibergrate offer pultruded lines under names like Safe-T-Span and Aqua Grate, with bearing bar profiles sized for rolling loads. The product also appears in odor-control flooring, manhole covers, and access platforms in wastewater treatment plants, where hydrogen sulfide would quickly attack steel.
Cutting and Installation Notes
FRP pultruded grating cuts with standard carbide-tipped or diamond-grit blades. A circular saw with a masonry or fiber cement blade works for straight cuts, while a jigsaw handles notches and penetrations. Cutting produces fine glass dust, so respiratory protection and long sleeves are essential. The cut edges should be sealed with a compatible resin coating to prevent moisture wicking into the exposed glass fibers, a step that is often skipped and shortens service life.
Panels are typically secured with stainless steel or FRP hold-down clips. Using steel clips on an FRP panel creates a galvanic and corrosion mismatch, so clip material should match the service environment. Expansion and contraction from temperature swings also require slightly oversized clip holes or slotted connections.
How to Specify the Right Panel
Start with the clear span between supports and the expected live load. That determines bearing bar depth, which commonly ranges from 1 inch to 2 inches for I-bar profiles. Next, confirm the chemical environment and select the resin system. Then check the surface finish: grit-top panels improve slip resistance in wet or oily areas, while concave or fine-grit surfaces suit barefoot or light-traffic zones. Finally, verify the open area percentage if drainage, airflow, or light transmission matters.
For buyers comparing alternatives, pultruded grating is often evaluated against Bar Grating in steel or aluminum, as well as Expanded Metal and Perforated Metal for lighter-duty covers. Grip Strut Grating offers slip resistance in metal form, but none of these match FRP for combined corrosion resistance and electrical non-conductivity. Platform Grating and Floor Grating are broader categories that include all of these materials, so the specification should name the material, resin, and profile rather than relying on a generic term.
Request a quote with the span, load, chemical exposure, and surface finish specified. A complete specification returns an accurate panel recommendation faster than a general inquiry for Fiberglass Grating.
